Product Detail

Key Features:
  • High Impact Resistance: Made with automotive-grade strengthened glass for superior impact and thermal shock resistance.
  • Custom Shaped Design: Supports complex outlines and cut-outs for dashboard displays, control panels, and touchscreens.
  • Precision Edge Finishing: Smooth chamfered edges and high-resolution silk printing enhance appearance and mechanical performance.
  • Optional Functional Coatings: Available with AR (anti-reflective), AF (anti-fingerprint), and AG (anti-glare) coatings for better display and user comfort.
  • Outstanding Optical Clarity: High transmittance and excellent color fidelity improve in-car display quality.
  • Strong Environmental Durability: Resistant to high temperatures, humidity, and UV radiation, ideal for all automotive environments.

Customized Option:
  • Materials Options: Soda Lime Glass,Mid-Aluminum Glass,High-Aluminum Glass
  • Available Thickness: 0.33 mm to 10 mm, customizable for different application needs.
  • Size & Shape: KS Glass offers various custom shapes and sizes tailored to your specifications.
  • Cutting Options: Laser Cutting,Water jet Cutting,Diamond Blade Cutting,CNC
  • Edge Options: Polished Edge,Safety Edge,Beveled Edge,Smooth Edge,2.5D Edge,Pencil Edge,Straight Edge
  • Tempering Options: Physical Tempered/Checmical Strengthened
  • Coating Options: Anti-Reflective (AR) Coating,Anti-Fingerprint (AF) Coating,Scratch-Resistant Coating(AS),Anti-Glare Coating(AG)
  • Printing Options: UV Printing,Silk screen printing,Laser engraving printing
  • Adhesive Options: AB Tape, Double-side Tape,3M Adhesive

Technical Parameters

Materials: Ultra Clear Glass
Shape: Irregular
Thickness: 2mmT
Edge Work: Safety edge+holes drilling
Tempered Method: Physical Tempering
Coating: Anti-fingerprint(AF) coating
Printing Method: Silk screen printing  #RAL9004 BK
Transmission Rate: ≥ 90.5%
Density: 2.5 g/cm³
Hardness: at least 6H
Strengthness: IK07
Operating Temperature Range: Suitable for -30°C to 250°C.
Thickness Tolerances:± 0.2mm
Dimensional Tolerances:±0.5mm for large size; ±0.1mm for small size
Weather Resistance: Strong resistance to high temperatures and humidity, reducing aging effects
UV Resistance: High UV-blocking capability
Impact Resistance: 2-5 times stronger than standard glass. Specific impact resistance can vary based on thickness and treatment.




Application

  • Automotive Center & Cockpit Displays: Widely used in dashboards, infotainment panels, and smart cockpits of modern vehicles, offering clarity, durability, and design integration for touch interaction and multi-display setups.
  • Smart Terminals & Consumer Electronics: Ideal for smart home panels, IoT terminals, and wearable tech interfaces requiring slim profiles, touch responsiveness, and customizable printing or shape.
  • Industrial Control Interfaces: Perfect for industrial control panels, automation terminals, and factory HMI displays, offering durability, chemical resistance, and precise fit with sensors or buttons.
  • Medical Display Covers: Used in diagnostic monitors and operating room equipment, requiring smooth edges, optical clarity, and easy sterilization.
  • Retail & Commercial Touch Interfaces: Compatible with POS systems, interactive kiosks, and smart vending machines, enhancing device aesthetics while providing screen protection.

Company and factory equipment

Customer Visit

Customer Visit

Company Profile

Company Profile

Dlivery & Payment

Packaging:

  • Step 1: PE film coating(Normally) / paper(For seashipment prevent wet).
  • Step 2: Kraft paper for fixation.
  • Step 3: Carton for glass safety protection.
  • Step 4: Custom make plywood case with hinge for custom(fumigation + convenient inspection) convenience.
  • Step 5: Packing strap for further fixation.
Company Profile
Customer Visit
Customer Visit
Customer Visit
