Product Detail

Key Features:
  • Ultra Clear Substrate: Made from high-transparency ultra clear glass, ensuring excellent light transmission and minimal color distortion.
  • 4mm Tempered for Strength: Heat-strengthened to improve impact resistance and durability under daily use or industrial environments.
  • High-End Black Silkscreen: Durable, precise black printing delivers a sleek, modern look while resisting fading and abrasion.
  • Smooth Polished Edges: All edges are carefully polished and chamfered for safety and aesthetics.
  • Customizable Shape & Logo: Supports custom cutouts, logo printing, and multi-color options for OEM/ODM projects.


Customized Option:
  • Available Thickness: Ranging from 0.1 mm to 15 mm, depending on the insulation requirements and specific applications.
  • Size & Shape: Supports special-shaped cutting to meet diverse needs. Customizes as per drawing.
  • Cutting Option: CNC Cutting/Water jet Cutting/Diamond Blade Cutting
  • Edge Options: Polished Edge/Safety Edge/Beveled Edge/Smooth Edge/2.5D Edge/Pencil Edge/Straight Edge
  • Tempering Options: Physical Tempered/Checmical Strengthened
  • Coating Options: Anti-Reflective (AR) Coating/Anti-Fingerprint (AF) Coating/Scratch-Resistant Coating/Indium Tin Oxide(ITO) Coating or Anti-Glare (AG)Coating
  • Printing Options: UV Printing/Silk screen printing/Laser engraving printing
  • Adhesive Options: AB Tape/ Double-side Tape/3M Adhesive

Technical Parameters

Materials: Ultra Clear Glass
Shape: Rectangular
Thickness: 4mmT
Edge Work: Safety edge by CNC machine
Tempered Method: Physical Tempered
Printing Method: Silk screen printing  #RAL9004 BK #RAL9001 WH
Density: 2.5 g/cm³
Hardness: at least 6H
Strengthness: IK07
Operating Temperature Range: Suitable for -30°C to 250°C.
Thickness Tolerances:± 0.2mm
Dimensional Tolerances:±0.5mm for large size; ±0.1mm for small size
Weather Resistance: Strong resistance to high temperatures and humidity, reducing aging effects
UV Resistance: High UV-blocking capability
Impact Resistance: 2-5 times stronger than standard glass. Specific impact resistance can vary based on thickness and treatment.





Application

  • Smart Touch Devices: It is widely used in modern smart touch devices, such as home automation panels, smart switches, access control systems, and smart locks. Its high clarity and precise printing ensure a seamless visual and tactile user experience.
  • Industrial Control Systems: Perfectly suited for human-machine interface (HMI) displays and operator panels in industrial automation environments. It is resistant to high temperatures, dust, and chemical corrosion, ensuring stable operation even under harsh working conditions.
  • Medical Equipment Interfaces: Used in diagnostic monitors, patient data terminals, and other medical instruments that demand hygiene, clarity, and resistance to cleaning agents. The polished edge and smooth surface make it suitable for sterile environments.
  • Consumer Electronics: Integrated into smart home appliances, kitchen control interfaces, and other high-end consumer electronics requiring both aesthetics and functionality. The black printing enhances UI design while the glass surface protects internal components.
  • Public Terminal Systems: Suitable for use in self-service kiosks, ticketing machines, and digital signage displays. It offers excellent durability and maintains a clean, professional appearance even after extended public use.
  • Automotive Interior Displays: Applicable to in-vehicle infotainment panels, dashboard touch screens, and center control displays that require strong anti-reflective properties and fingerprint resistance.

Company and factory equipment

Customer Visit

Customer Visit

Company Profile

Company Profile

Dlivery & Payment

Packaging:

  • Step 1: PE film coating(Normally) / paper(For seashipment prevent wet).
  • Step 2: Kraft paper for fixation.
  • Step 3: Carton for glass safety protection.
  • Step 4: Custom make plywood case with hinge for custom(fumigation + convenient inspection) convenience.
  • Step 5: Packing strap for further fixation.
