| AGC Dragontrail™ Glass | AGC Leoflex™ Glass | AGC Clear Float Glass | AGC Planibel Low-E Glass | |
| Softening Point | ~720°C | ~750°C | ~700°C | ~700°C |
| Annealing Point | ~560°C | ~570°C | ~550°C | ~550°C |
| Strain Point | ~510°C | ~520°C | ~500°C | ~500°C |
| Maximum Operating Temperature | Up to 150°C | Up to 160°C | Up to 120°C | Up to 100°C |
| Thermal Expansion Coefficient (20°C to 300°C) | 9.2 x 10⁻⁶ /K | 8.7 x 10⁻⁶ /K | 9 x 10⁻⁶ /K | 9 x 10⁻⁶ /K |
| Thermal Conductivity | 1.1 W/m·K | 1.1 W/m·K | 1.0 W/m·K | 0.9-1.0 W/m·K |
| Refractive Index | 1.51 | 1.52 | 1.52 | 1.52 |
| Light Transmittance | Up to 91% | Up to 92% | 90- 92% | 78-82%(depends on coating) |
| UV Cut-off Wavelength | ~320 nm | ~330 nm | ~300 nm | ~310 nm |
| Solar Energy Transmittance | ~85% | ~88% | ~80% | 40-60%(depends on coating) |
| Coefficient of Thermal Stress | ~20 MPa/°C | ~19 MPa/°C | ~18 MPa/°C | ~16 MPa/°C |
| Density | 2.4 g/cm³ | 2.5 g/cm³ | 2.5 g/cm³ | 2.5 g/cm³ |
| Young's Modulus | 73 GPa | 74 GPa | 72 GPa | 71 GPa |
| Hardness (Moh’s Scale) | 6-7 | 6.5-7 | 5-6 | 5-6 |
| Poisson's Ratio | 0.23 | 0.22 | 0.23 | 0.23 |
| Bending Strength | ~700 MPa | ~750MPa | ~600MPa | ~550MPa |
Customer Visit
Company Profile
Ready to take your glass project to the next level? Contact us today to discuss your custom glass needs and get a quote!
contact us
KS GLASS specializes in the production of high-quality glass products. With advanced technology and expertise, we offer solutions tailored to meet the diverse needs of our customers. Our products are known for their durability, precision, and reliability. We are committed to innovation and excellence in manufacturing, ensuring that every product meets industry standards while catering to specific client requirements.
