1.1mm High-Transparency Durable Ultra Clear Glass Slides for Laboratory and Optical Testing

Key Features:

• Premium Ultra-Clear Glass: Manufactured from high-quality ultra-white glass, providing excellent transparency, low iron content, and superior optical clarity for precise observation.

• Printed Frosted White Area for Labeling: One end features a printed frosted white section designed for easy writing and sample identification, ensuring convenient laboratory workflow.

• Chemically Strengthened for Durability: Enhanced strength to resist accidental breakage, scratches, and impact during repeated handling in busy lab environments.

• Safety Edge Grinding: All edges are finely ground and polished to prevent sharpness and ensure safe handling, reducing the risk of injury during use.

• Excellent Chemical Resistance: Suitable for contact with common laboratory reagents without compromising glass integrity or clarity.

• Consistent Thickness and Size Accuracy: Precision manufacturing guarantees dimensional stability, ensuring compatibility with standard laboratory equipment.

• Customizable Options: Available in standard size (25×75 mm) and thickness (1.1 mm), with customization for size, printed area, logo, and additional features like anti-fingerprint coating.

Customized Option:

• Available Thickness: Ranging from 0.1 mm to 15 mm, depending on the insulation requirements and specific applications.

• Size & Shape: Supports special-shaped cutting to meet diverse needs. Customizes as per drawing.

• Cutting Option: CNC Cutting/Water jet Cutting/Diamond Blade Cutting

• Edge Options: Polished Edge/Safety Edge/Beveled Edge/Smooth Edge/2.5D Edge/Pencil Edge/Straight Edge

• Tempering Options: Physical Tempered/Checmical Strengthened

• Coating Options: Anti-Reflective (AR) Coating/Anti-Fingerprint (AF) Coating/Scratch-Resistant Coating/Indium Tin Oxide(ITO) Coating or Anti-Glare (AG)Coating

• Printing Options: UV Printing/Silk screen printing/Laser engraving printing

• Adhesive Options: AB Tape/ Double-side Tape/3M Adhesive

• Materials: Ultra Clear Glass

• Shape: Rectangular

• Thickness: 1.1mmT

• Edge Work: Safety edge by CNC machine

• Tempered Method: Chemical Strengthened

• Printing Method: Silk screen printing  RAL9001 WH

• Density: 2.5 g/cm³

• Hardness: at least 6H

• Strengthness: IK07

• Operating Temperature Range: Suitable for -30°C to 250°C.

• Thickness Tolerances:± 0.2mm

• Dimensional Tolerances:±0.5mm for large size; ±0.1mm for small size

• Weather Resistance: Strong resistance to high temperatures and humidity, reducing aging effects

• UV Resistance: High UV-blocking capability

• Impact Resistance: 2-5 times stronger than standard glass. Specific impact resistance can vary based on thickness and treatment.

• Microscopy and Biological Research: Ideal for mounting biological, chemical, and medical specimens under microscopes, ensuring clear imaging and reliable analysis.

• Medical Diagnostics and Clinical Testing: Frequently used in pathology, cytology, and hematology labs for diagnostic testing that requires accurate labeling and sample security.

• Pharmaceutical and Chemical Laboratories: Suitable for drug research, chemical analysis, and quality control processes where durability and precision are critical.

• Optical and Industrial Inspection: Applied in optical testing, material analysis, and industrial quality inspection for high-precision evaluations.

• Educational and Research Institutions: Perfect for use in universities, colleges, and R&D facilities conducting advanced scientific studies and experiments.

• Customized Solutions for Specialized Testing: Can be tailored for use in specialized equipment or niche laboratory processes requiring specific sizes, coatings, or printed designs.
