Product Detail

Key Features:
  • IK07 Impact Resistance: This glass panel conforms to the IK07 impact standard, offering excellent resistance to mechanical shock and ensuring product reliability in demanding environments.
  • 3mm Ultra Clear Tempered Glass: Manufactured from low-iron ultra-clear glass, providing over 90% light transmittance while maintaining exceptional strength after physical tempering.
  • Black and White Silkscreen Printing: High-resolution black and white silkscreen layers are applied in a cleanroom environment, offering rich contrast, excellent adhesion, and long-lasting aesthetics.
  • Safety Edge Polishing: All edges are finely polished with rounded corners to eliminate sharpness, improving handling safety and visual appearance.
  • Custom Shape and Print Support: Supports a wide range of customization, including logo printing, button indicators, or window openings for display and sensors.

Customized Option:
  • Available Thickness: Ranging from 0.1 mm to 15 mm, depending on the insulation requirements and specific applications.
  • Size & Shape: Supports special-shaped cutting to meet diverse needs. Customizes as per drawing.
  • Cutting Option: CNC Cutting/Water jet Cutting/Diamond Blade Cutting
  • Edge Options: Polished Edge/Safety Edge/Beveled Edge/Smooth Edge/2.5D Edge/Pencil Edge/Straight Edge
  • Tempering Options: Physical Tempered/Checmical Strengthened
  • Coating Options: Anti-Reflective (AR) Coating/Anti-Fingerprint (AF) Coating/Scratch-Resistant Coating/Indium Tin Oxide(ITO) Coating or Anti-Glare (AG)Coating
  • Printing Options: UV Printing/Silk screen printing/Laser engraving printing
  • Adhesive Options: AB Tape/ Double-side Tape/3M Adhesive

Technical Parameters

Materials: Ultra Clear Glass
Shape: Irregular
Thickness: 3mmT
Edge Work: Safety edge by CNC machine
Tempered Method: Physical Tempering
Coating: Anti-fingerprint(AF) coating & Anti-scratch(AS) coating
Printing Method: Silk screen printing  #RAL9004 BK #RAL9001 WH
Density: 2.5 g/cm³
Hardness: at least 6H
Strengthness: IK07
Operating Temperature Range: Suitable for -30°C to 250°C.
Thickness Tolerances:± 0.2mm
Dimensional Tolerances:±0.5mm for large size; ±0.1mm for small size
Weather Resistance: Strong resistance to high temperatures and humidity, reducing aging effects
UV Resistance: High UV-blocking capability
Impact Resistance: 2-5 times stronger than standard glass. Specific impact resistance can vary based on thickness and treatment.

Application

  • Smart Control Panels: Ideal for home appliances, smart touch switches, and thermostats where durability, aesthetic value, and sensor functionality are required.
  • Industrial User Interfaces: Well-suited for industrial HMIs, instrument panels, and display terminals, providing rugged protection in harsh environments.
  • Medical Equipment Panels: Used in medical monitoring and diagnostic devices where easy cleaning, chemical resistance, and high safety are essential.
  • Consumer Electronics: Supports control panels of electronic appliances, water purifiers, and kitchen automation systems with personalized printing options.

Company and factory equipment

Customer Visit

Customer Visit

Company Profile

Company Profile

Dlivery & Payment

Packaging:

  • Step 1: PE film coating(Normally) / paper(For seashipment prevent wet).
  • Step 2: Kraft paper for fixation.
  • Step 3: Carton for glass safety protection.
  • Step 4: Custom make plywood case with hinge for custom(fumigation + convenient inspection) convenience.
  • Step 5: Packing strap for further fixation.
